100Nm/200/500 the torsion rig controlled by micro-computer
一、扭转试验台简介
The simple introduce about torsion rig
该试验台主要用于零部件的检测。被测试试样安装在可调整空间的夹具之间，可适应不同的被测试试样扭转力学性能的试验。试验台采用计算机控制操作，可进行扭矩、峰值、角度、曲线等数据的采集；显示器显示被测试零件的扭矩-时间，扭角-时间，扭矩-扭角试验曲线；可以实现试验数据存储、考取、打印试验报表等。
The rig is mainly used for detecting the parts. The detected samples are installed between the fixtures which can adjust the test of torsion behavior of all kinds of detecting samples. The rig can collect data about torque, peak, angle and curve, which is operated by computer controlling. The screen displays the testing curve about detecting parts on torque-time, torque-torsional angle, torque- tensional angle. And it also can realize the testing data of preservation and the printing of testing chart.
二、技术参数:
The technological parameters
1. 样式：卧式
Pattern: horizontal
2. 最大试验力：100Nm/200/500Nm
Maximum force: 100 Nm/200Nm/500Nm
3. 试验力分辨率：0.01Nm
The resolution of testing force: 0.01Nm
4. 精确测量范围: 1%FS-100%FS；
The range of accurate measurement: 1%FS-100%FS
5. 角度分辨率：0.01°
The resolution of angle:0.01°
6. 试验行程：500mm
The testing stroke: 500mm
7.扭转速度控制范围：0.1°/min～720°/min 无极调速
The range of torsion speed: 0.1°/min～720°/min Steeples-speed
8.试验机级别：1级
The level of torsion rig: superior quality
9.外观：应符合GB/T2611要求
Appearance: meet the GB/T2611 requirements
10.成套性：符合标准要求
The complete set: meet the standards
11.保护功能：试验机有过载保护功能
The function of protection: over-protected
12.供电电源：220V，50Hz
The electricity supply: 220V，50Hz
